Overall length: 4065 mm (160 in.)
Overall width (minimum tread): 2220 mm (87.4 in.)
Overall height: 2675 mm (105.3 in.)
Wheel base: 2435 mm (95.5 in.)
Tread Front: 1550 mm (61.02 in.), 1650 mm (64.96 in.)
Rear 1760 to 2090 mm (69.30 to 82.28 in.)
Minimum ground clearance: 435 mm (17.1 in.) (drawbar bracket)
Weight: 3650 kg (8047 lbs)
Model: V3307-DI-TI
Type: Vertical, Water-Cooled, 4-cycle diesel engine
No. Cylinders: 4
Power: 79.4 kW (106 Hp)
Battery Capacity: 12 V
Fuel Tank Capacity: 175 L
Standard tire size: Front 13.6-24
Rear 18.4-34
Clutch: Hydraulic wet disc
Steering: Full hydraulic power steering
Transmission: Hydraulic shuttle shift, fully synchronized main shift, 16F/16R
Brake: Traveling Wet type multiple disc (hydraulic)
Parking Wet type multiple disc (mechanical)
Differential: Bevel gears with differential lock (front and rear)
Hydraulic control system: Position, draft and mix control
Pump capacity: 65.0 L/min.
Three point hitch: Category 2
Independent clutch: Wet type, multiple disc
Independent PTO Direction of turning. Clockwise, viewed from tractor rear
PTO speed 6 spline: 540 (rpm)
Traction system Swing drawbar, adjustable in direction.
