Overall Length: 3,760mm
Overall Width (minimum tread): 2,010mm
Overall Height: 2,535mm (Muffler)
Wheel Base: 2,250 (95.9 in.)
Tread: Front: 1,660mm
Minimum Ground Clearance: 450mm (Drawbar Jacket)
Weight: 2,710 kg
<a href=”https://brixtonagroindustrialmachinery.com/wp-content/uploads/2025/03/M9540_PDF.pdf”><button>Download Brochure</button></a>
Model: V3800-DI-T
Type: Direct Injection, liquid cooled 4 cylinder diesel
No. of Cylinders: 4
Power: 70.8 kW (95 HP)
Battery Capacity: 12 V
Fuel Tank Capacity: 90 L
Standard Tire Size Front: 12.4-24
Rear: 18.4-30
Clutch: Dry Single Plate
Steering: Hydraulic power steering
Braking system: Hydraulic wet discs
Differential: Bevel gears with different lock (Rear)
Hydraulic control system Position, draft (top link sensing) and mix control
Pump Capacity 69.3 L/min
Three Point Hitch Category 2
Remote Hydraulic Control One remote valve
Traction System Swinging drawbar, adjustable in direction
Direction of Turning Clockwise, viewed from tractor rear
PTO Engine Speed 6 spline: 540/2205
