Overall length (without 3p): 2410 mm (94.88 in.)
Overall width: 1015, 1105 mm (39.96, 43.50 in.)
Overall height (with ROPS): 1960 mm (77.16 in.)
Wheel base: 1563 mm (61.54 in.)
Minimum ground clearance: 325 mm (12.7 in.)
Tread Front: 815 mm (32.1 in.)
Rear: 810, 900 mm (31.9, 35.4 in.)
Weight: 625 kg (1380 lbs)
Model: D1005-E2-D3IT
Type: E-TVCS, liquid cooled, 3 cylinder diesel
Number of cylinder: 3
Engine gross power: 17.87 kW (23.96 Hp)
Fuel tank capacity: 23 L
Tire: Front 180/85D12
Rear: 8.3-20
Steering: Integral type power steering
Transmission: Gear shift, 9 forward and 3 reverse
Brake: Wet disc type
Min. Turning radius (with brake): 2.1 m (6.9 feet)
Clutch: Dry single plate
Hydraulic control system: Position valve
3 point hitch: ISO Category 1N
PTO System
Rear PTO: SAE 1-3/8, 6 splines
PTO/ Engine speed: 540 (rpm) at 2504 (rpm), 980 (rpm) at 2510 (rpm)
