DC-70 PRO PH Combine Harvester

Description

Engine

Name: Kubota V2403-M-DI-TE-CS2T
Type: Water-cooled 4-cycled 4-cylinder vertical diesel engine (with turbo charger)
Total displacement (L): 2.434
Output/ Rotation speed: 50.7 kW [69.0 PS] / 2700
Fuel Tank Capacity: 85 L
Battery: 12V

Travel Section

Center distance: 1250 mm
Crawler: Width x Ground contact length 500 x 1700 mm
Minimum ground clearance: Minimum ground clearance 325mm
Speed shift system: HST 3-Range (3F/3R)
Travel Speed: Forwad/Backward Low: 0 – 0.97 Middle: 0 – 1.37 High: 0-1.85

Reaper Section

Reel: Diameter x Width: 900 x 1903 mm
Up/down control Hydraulic system
Gathering length: 2075 mm
Clutter Bar length:

Hopper

Hopper Capacity 500 L / approx. 300 kg
Number of units, Take-out system
2/ Bagging

Harvesting Capacity

0.3 – 0.62 for Rice
